Steel shield

The protective cover of steel plate is well sealed, which can prevent iron chip, cooling fluid and accidental accident of tools.

1. Strong and durable, stable operation, low noise and beautiful appearance.

2. The steel plate protective cover is suitable for the rail protection of high-speed moving machine tools, which is stable without vibration noise.

3. The steel plate shield device not only protects the service life of the plate, but also ensures the precision of the machine tool.

4. Each shield of the steel plate is opened in parallel at the same time and retracted in parallel at the same time, making it run freely.

5. The steel plate protective cover will not make the protective plate out of joint, and there will be collision sound, which is not only beautiful but also improves the service life of the protective plate.

6. On the basis of the original sealing tape, a layer of stainless steel cover plate was added to prevent the iron chip from burning at high temperature from rubbing into the rail surface and pulling the guide rail.

Advantages of steel plate protective cover device:

1. Each piece of the cover can be fired simultaneously, which is completely different from the general one-piece pull of the cover, so the noise is extremely low.

2. The protective cover of the device can increase the service life.

3. The steel shield device can raise the moving speed of the shield to 120m/min and bear a higher G value (2G).

4. The steel plate protective cover device makes the protective cover move together and parallel (avoiding the disadvantages of snaking in the general shear type protective cover).

5. It can be more stable at high speed without vibration.

Guide rail protection cover for steel plate and stainless steel plate machine tool

The steel telescopic guide rail guard is a traditional form of protection for machine tools.Steel telescopic guideway cover in this field were widely used, to prevent scraps and other sharp objects into play an effective protection, through some structural measures and proper scrapings plate can effectively reduce the cooling fluid infiltration.The steel telescopic guide-rail protective cover of our factory can meet the requirements of high technology, correct installation position and high running speed of modern machine tools.

Technical data

The steel telescopic guide rail guard is made of high quality 2-3mm thick steel plate formed by cold pressing, which can also be made of stainless steel according to the requirements.A special surface polish will add value.We can provide the appropriate guide rail protection types (horizontal, vertical, inclined and horizontal) for all machine tool types.

According to the different running speed and guide rail, the protective cover structure we developed is also different.We have a polyurethane or brass slider running at a speed of 10m/min.At a moderate speed of 30m/min, we have a roller.In addition, a buffer system is needed between the drive plate, the chip scraper and the chip absorber.The purpose of the slider buffer system is to reduce collision, noise and friction.

The number of sections of the steel telescopic guide rail guard is important to its ratio, weight and operating characteristics.Each single section should be as long as possible, which can reduce the number of sections and reduce the cost.In general, the minimum compression ratio should be between 3:1 and 5:1.
